EasyGate IM
Back to products
EasyGate Elite / EliteS

EasyGate Superb

Type

  • Swinging technology

  • 1 wing / 2 wings

  • Square front

Safety & Security Detection

  • 24 pairs of IR sensors

  • Safety & Security levels

  • Tailgating / Cross over detection

ขอรายละเอียด

Dimensions

mm inches
Cabinet height 990 mm 38.98”
Cabinet length 1,580 mm 55.12”
Cabinet width 99 mm 3.95”
Barrier height standard 990 mm 38.98”
Barrier height max. 1,800 mm 70.87”
Passage width standard 650 mm 25.59”
Passage width max. 1,100 mm (for height of glass wing up to 1,400 mm) 43.31”
920 mm (for height of glass wing up to 1,800 mm) 36.22”

Special features

  • Wide passage lane

  • Arc Layout

  • Flag wing

Standard Materials and Colours

  • Frame: black RAL

  • Covers: brushed stainless steel

  • Top Lid: black glass

  • Barriers: tempered glass barrier panels (10 mm / 0.39”)

  • Side Infill Panel: tempered glass panels (6 mm / 0.24”)

Operating Environment

Indoor

Drive Mechanism

  • Fail-Safe

  • MCBF: 5,000,000 cycles

Stand-by Power Consumption

  • 22.6 W

Emergency Mode

  • Open automatically in the exit direction

Optional Accessories

  • RFID reader bracket (flush mounted)

  • Access Light / Lane Light / Passage Light

  • WAV player

  • Pressure sensing top

  • RF remote control

  • EasyTouch / TouchPanel / T-MON SW

  • SuperCap (emergency power back-up)

  • Alternative surface finishes / Optional top Finishes

  • Integration of LiftCall / Card collector / BarCode scanner

  • Ramp LT
